45° Double Miter Saw for Accurate Wood Joint Processing
Outstanding Features
• This double miter saw can cut two 45 degree angles for perfect 90 degree joints.
• The machine has magnetic switch with thermal overload protection.
• Saw blade raising and lowering speed controls can be adjusted for different wood material cutting.
• Foot switch provides operators with convenient control for machine start.
• Two side wings support long stock and the stop can be set for cutting multiple pieces of uniform length.
• When open the front guard, the machinery will disconnect power immediately for safety reason.
Applications
Specifications
| MODEL | JDS-300W | JDS-350W |
|---|---|---|
| Angle of cutting | 45˚ | |
| Cutting capacity | 70 mm / 2-3/4" (Wide) 70 mm / 2-3/4" (Thick) |
90 mm / 3-1/2" (Wide) 90 mm / 3-1/2" (Thick) |
| Table height from floor | 860 mm (34") | |
| Production speed | 20 cuts / minute | |
| Spindle diameter | φ 25.4 mm (φ1") | |
| Spindle speed | 3,200 RPM (60HZ) | |
| Saw blade | 305 x φ25.4 mm x 120T (12" x φ1" x 120T) | 355 x φ25.4 mm x 120T (14" x φ1" x 120T) |
| Motor | 2 HP x 2 | |
| Side clamping system | N / A | Side-clamps (2 pieces) |
| Air pressure required | 5 kg / cm² (71 psi / 5 bar) | |
| Extension table length | 1,200 mm / 47.2" (in & out feeding) | |
| Machine over size | 6,750 x 3,780 x 1,470 mm | |
| Packing size (L x W x H) | 1,500 x 900 x 1,620 mm | 1,490 x 880 x 1,650 mm |
| N.W. / G.W . | 355 kgs / 402 kgs | 480 kgs / 590 kgs |
| OPTIONAL ACCESSORY | ||
| MODEL | JDS-300W | JDS-350W |
| Clamping system | Not included | Not included |
- JELY reserves the right to change or modify specification and system apperance without further notices. Actual system appearance may vary.
